HPE ProLiant DL360 Gen11 4510 2.4GHz 12-

Descriere

Lifecycle

• Obsolete Date 31-01-2027

Specifications

• Accelerators Optional
• Included memory 64 GB (2x32 GB, 5600 MT/s)
• Memory type HPE DDR5 Smart Memory
• Expansion slots 2-slots (x16 FH, x16 HH) as standard. Upgradeable to 3rd slot in HH (or remove Slot 2 bracket to be FH at Slot 3) in a 2nd processor configuration. And maximum 2 OCP 3.0 PCIe5 slots.
• Processor number 1 processor included
• Processor speed 2.40 GHz
• Processor cache 30 MB L3
• Processor core available 12 core
• Storage controller HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
• Optical drive type Optional - HPE 9.5mm SATA DVD-RW Optical Drive, HPE Mobile USB DVD-RW Drive
• Network controller Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
• Warranty 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit https://www.hpe.com/support
• Security UEFI Secure Boot and Secure Start support. Intel® Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs
• Power supply type 2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
• Included drives 2x HPE 960GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• System fan features 5x Standard Fans
• Infrastructure management Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional - HPE iLO Advanced, HPE OneView Advanced and HPE Compute Ops Management (optional subscription available)
• Form factor 1U Rack
• Processor name Intel® Xeon® Silver 4510 (12 core, 2.40 GHz, 30 MB L3, 150W)

Quickspecs

• QuickSpecs
• QuickSpecs (HTML)
• QuickSpecs
• QuickSpecs (PDF)

Overview

Are you looking for a scalable, compute-dense solution for hybrid cloud or other data workloads in a virtualized and containerized environment? The HPE ProLiant DL360 Gen11 server is a rack-optimized, 1U 2P solution that delivers exceptional compute performance, upgraded high-speed data transfer rate, and memory depth at 2P compute capability. Powered by 4th and 5th Gen Intel® Xeon® Scalable Processors with up to 64 cores, 8 TB of memory, and 20 EDSFF drives as well as increased memory bandwidth and high-speed PCIe Gen5 I/O, the HPE ProLiant DL360 Gen11 server is a perfect solution for Electronic Design Automation (EDA), CAD, and VDI. The HPE ProLiant 360 Gen11 server is engineered to optimize IT with a cloud operating experience, built-in security, and optimized performance for workloads to drive your business forward.

What's new

• Powered by 5th Gen Intel® Xeon® Scalable Processors that supports up to 64 cores & 385W, and 16 DIMMs for up to 8 TB of high bandwidth DDR5 memory up to 5600 MHz.
• 16 DIMMs per processor for up to 8 TB total DDR5 memory per server with increased performance, High Bandwidth Memory (HBM) support, and lower power requirements.
• Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2 x16 PCIe Gen5 and 2 OCP slots.
• Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
• Supports up to three single-wide (SW) GPUs[1] to accelerate graphic intense workloads.
• Supports Liquid Cooling Modules for highest thermal design points (TDPs).

Features

Optimized Performance for your Workloads: Accelerated, Open, and Efficient

The HPE ProLiant DL360 Gen11 server provides real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.

The HPE ProLiant DL360 Gen11 server is an excellent choice for EDA, CAD, CDN, general-purpose virtualization workloads (including large-scale VDI), Inteligent Video Analytics, and Platforms (VCF & Containers) that require increased compute density with built-in security and flexibility.

Harness major computer performance. The HPE ProLiant DL360 Gen11 server is powered by the 4th and 5th Gen Intel® Xeon® Scalable Processors with next-generation technology that supports up to 64 cores, 385W, and up to 8 TB of memory.

The HPE ProLiant DL360 Gen11 server provides advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 3 x16 PCIe Gen5 and 2 OCP slots to improve I/O throughput and reduce latency.

The server provides 16 DIMMs per processor for up to 8 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.

Powered by 4th and 5th Gen Intel® Xeon® Scalable Processors, adds hardware- and software-assisted security features, including Intel® Software Guard Extensions and Intel® Boot Guard, which help secure the server hardware foundation on which critical apps run and better protect data in memory.

HPE ProLiant Gen11 servers continuously protect healthy servers by a) providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies malicious code, and b) securing servers at the edge with IDevID certificates installed by default.

HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, and data connections, providing a fast path to bring a server back online and into normal operations.

Embedded in Hewlett Packard Enterprise servers, HPE Integrated Lights-Out 6 (iLO 6) is an exclusive core intelligence that monitors server status, providing the means for reporting, ongoing management, service alerting, and local or remote management to quickly identify and resolve issues.

Intuitive Cloud Operating Experience: Simple, Self-service, and Automated

HPE ProLiant DL360 Gen11 servers are engineered for your hybrid world. ProLiant DL360 Gen11 servers are powered by 4th and 5th Gen Intel® Xeon® Scalable Processors and simplify the way you control your business’s compute—from edge to cloud—with a cloud operating experience.

Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a self-service console.

Automate tasks for efficiency in deployment, instant scalability, and seamless, simplified support and lifecycle management to reduce and shorten maintenance windows.

Self-service automated experiences are engineered and built into all HPE ProLiant Gen11 servers, whether purchased as physical servers or consumed as-a-service using HPE GreenLake as your compute and storage demands grow.

Simplify and secure server management from edge to cloud with HPE Compute Ops Management. HPE Compute Ops Management is an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire compute landscape, globally.

Trusted Security by Design: Uncompromising, Fundamental, and Protected

The HPE ProLiant DL360 Gen11 server utilizes the HPE Silicon Root of Trust, HPE’s fundamental approach to security that provides zero-trust architecture at the silicon level and ensures all server essential firmware is free from malware or compromised code.

Media

HPE ProLiant DL360 Gen11 virtual tour animated video

The HPE ProLiant DL360 Gen11 server is a perfect rack-optimized, 1U 2P, dense solution for general-purpose virtualization workloads that require increased compute density with built-in security and flexibility.

HPE ProLiant Gen11 servers with Intel Xeon - animated video

New HPE ProLiant Gen11 servers are engineered for the hybrid world to deliver an intuitive cloud operating experience, trusted security by design, and optimized performance – all while supporting a wide range of workloads that enable businesses to modernize and accelerate new innovations.

HPE ProLiant Gen11 servers with 4th Gen Intel® Xeon® Scalable Processors | Chalk Talk

In this Chalk Talk, learn about the new portfolio of HPE ProLiant Gen11 servers with 4th Gen Intel® Xeon® Scalable Processors.

HPE ProLiant Gen11 - Intel family - brief animated tour video for social media

New HPE ProLiant Gen11 servers are engineered for the hybrid world to deliver an intuitive cloud operating experience, trusted security by design, and optimized performance.

Compatible products

• Intel Xeon-Silver 4410Y 2.0GHz 12-core 150W Processor for HPE
• HPE 2.4TB SAS 12G Mission Critical 10K SFF BC 3-year Warranty 512e Multi Vendor HDD
• HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
• HPE 300GB SAS 12G Mission Critical 10K SFF BC 3-year Warranty Multi Vendor HDD
• Xilinx X2522-25G-PLUS Ethernet 10/25Gb 2-port SFP28 Adapter for HPE
• HPE 1800W-2200W FS Ti Ht Plg PS Kit
• HPE ProLiant DL3X0 Gen11 1U 2P Standard Fan Kit
• HPE 3.2TB NVME MU SFF BC U.3 PM1735A SSD
• HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
• HPE 1.92T NVMERI SFF BC U.3ST V2 MV SSD
• HPE 1TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
• HPE 3.2TB SAS 24G Mixed Use SFF BC Multi Vendor SSD
• HPE 2TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
• HPE MR416I-P GEN11 SPDM STORAGE CNTLR
• HPE 6TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD
• HPE DL360 G11 2SFF x4 U.3 BC TM Kit
• HPE 64GB 2Rx4 PC5-4800B-R Smart Kit
• HPE 8TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD
• HPE 16TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e ISE Multi Vendor HDD
• HPE ProLiant DL3X0 Gen11 1U Standard Heat Sink Kit
• Broadcom BCM57504 Ethernet 10/25Gb 4-port SFP28 Adapter for HPE
• HPE SN1610Q 32Gb 1-port Fibre Channel Host Bus Adapter
• HPE 7.68TB SATA RI SFF BC MV SSD
• HPE 8TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD
• HPE Bezel Lock Kit
• HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE Smart Storage Hybrid Capacitor with 145mm Cable Kit
• HPE 480GB SATA 6G Mixed Use SFF BC Multi Vendor SSD
• HPE 7.68T NVMERI SFF BC U.3ST V2 MV SSD
• HPE 900GB SAS 12G Mission Critical 15K SFF BC 3-year Warranty Multi Vendor HDD
• HPE ProLiant DL36X Gen10 Plus High Performance Fan Kit
• HPE C13 - C14 WW 250V 10Amp 2.0m Jumper Cord
• HPE DDR4 DIMM Blank Kit
• HPE 2TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
• HPE BladeSystem c-Class Virtual Connect 1G SFP SX Transceiver
• HPE DL3XX GEN11 1U BEZEL KIT
• BCM 57414 10/25GbE 2p SFP28 Adptr
• INT XEON-G 6526Y CPU FOR HPE
• HP OV 3yr 24x7 Supp Flex E-LTU
• HPE 100Gb QSFP28 MPO SR4 100m Transceiver
• Intel Xeon-Silver 4510 2.4GHz 12-core 150W Processor for HPE
• HPE DL360 GEN11 HIGH PERF HEAT SINK KIT
• HPE 100GbE QSFP28 SR4 100m Transceiver
• HPE SN1610Q 32Gb 2-port Fibre Channel Host Bus Adapter
• HPE 3.84TB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE InfiniBand HDR100/Ethernet 100Gb 2-port QSFP56 PCIe4 x16 MCX653106A-ECAT Adapter
• HPE ProLiant DL360 Gen11 Storage Controller Enablement Cable Kit
• HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
• Intel Xeon-Gold 5416S 2.0GHz 16-core 150W Processor for HPE
• HPE 1.92TB SATA 6G Mixed Use SFF BC Multi Vendor SSD
• Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T Adapter for HPE
• HPE 96W Smart Storage Lithium-ion Battery with 145mm Cable Kit
• HPE 1.92TB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE BladeSystem c-Class 10Gb SFP+ SR Transceiver
• HPE 32GB 2RX8 PC5-5600B-R SMART KIT
• HPE 960GB SATA 6G Mixed Use SFF BC Multi Vendor SSD
• HPE 600GB SAS 10K SFF BC MV HDD
• HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features
• HPE Gen9 LFF HDD Spade Blank Kit
• HPE 12TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e Multi Vendor HDD
• HPE 1.8TB SAS 10K SFF BC 512E MV HDD
• HPE 4Y TC BAS DL360 GEN11 HW SVC
• HPE 6TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD
• Intel I350-T4 Ethernet 1Gb 4-port BASE-T Adapter for HPE
• HPE 20TB SATA 7.2K LFF LP ISE MV HDD
• HPE 4TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
• HPE Proliant DL/ML Startup Service
• HPE Proliant DL/ML Install Service
• HPE 5 Year Tech Care Basic DL360/DL365 Gen11 Smart Choice Service
• HPE 9.5mm SATA DVD-RW Optical Drive
• HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
• HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller
• HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
• INT XEON-G 6426Y CPU FOR HPE
• INT XEON-G 6430 CPU FOR HPE
• Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
• HPE 1.92TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 PM1733a SSD
• MLX MCX631102 10/25GBE 2P SFP28 ADPTR
• HPE 3 Year Tech Care Essential DL360/DL365 Gen11 Smart Choice Service
• HPE ProLiant DL300 Gen10 Plus 1U Cable Management Arm for Rail Kit
• HPE BladeSystem c-Class 10Gb SFP+ LR Transceiver
• INT Xeon-G 5418Y CPU for HPE
• HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit
• HPE 4TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD
• HPE 960GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE 960GB SAS 12G Mixed Use SFF BC Value SAS Multi Vendor SSD
• HPE 3 Year Tech Care Basic DL360/DL365 Gen11 Smart Choice Service
• HPE Small Form Factor Hard Drive Blank Kit
• HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features
• HPE 5 Year Tech Care Essential DL360/DL365 Gen11 Smart Choice Service
• HPE SN1610E 32GB 2P FC HBA
• HPE MR216i-p Gen11 SPDM Storage Cntlr
• HPE 16GB 1RX8 PC5-5600B-R SMART KIT
• INT Xeon-G 6530 CPU for HPE
• HPE Mobile USB DVD-RW Optical Drive
• HPE 1.6TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 PM1735a SSD
• HPE 64GB 2Rx4 PC5-5600B-R Smart Kit
• HPE 32GB (1x32GB) Dual Rank x8 DDR5-4800 CAS-40-39-39 EC8 Registered Smart Memory Kit
• HPE ProLiant DL360 Gen11 OROC Tri-Mode Cable Kit
• HPE ProLiant DL3X0 Gen11 1U High Performance Fan Kit
• HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features
• Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T OCP3 Adapter for HPE
• Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE
• HPE 16TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e ISE Multi Vendor HDD
• HPE 16GB 1RX8 PC5-4800B-R SMART KIT
• BCM 57412 10GBE 2P SFP+ OCP3 ADPTR
• Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ Adapter for HPE
• INT XEON-S 4514Y CPU FOR HPE
• HPE 32GB microSD RAID 1 USB Boot Drive
• HPE DL360 Gen11 2SFF TM Cbl Kit
• HPE 240GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE 3.84TB SAS RI SFF BC VS MV SSD
• HPE MR416I-O GEN11 SPDM STORAGE CNTLR
• HPE 960GB SATA 6G Read Intensive LFF LPC Multi Vendor SSD
• HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features
• HPE MR216i-o Gen11 SPDM Storage Cntlr
• HPE 7.68TB SAS 12G Read Intensive SFF BC Value SAS Multi Vendor SSD
• HPE 25Gb SFP28 SR 100m Transceiver
• Intel I350-T4 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
• HPE 12TB SAS 12G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e Multi Vendor HDD
• HPE 1.2TB SAS 12G Mission Critical 10K SFF BC 3-year Warranty Multi Vendor HDD
• HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device
• HPE 9.5mm SATA DVD-ROM Jb Gen9 Kit

Documents

• HPE ProLiant DL360/DX360 Gen11 #UKDoC TPS-I022
• HPE ProLiant DL360 Gen11 QuickSpecs
• HPE ProLiant DL360 Gen11 - Carrier Grade Supplement QuickSpecs
• HPE Reference Configuration for Red Hat OpenShift Container Platform 4.12 on HPE ProLiant DL360 and DL380 Gen11 Servers
• Fogsphere transforms workplace safety with AI and HPE technology
• Optimizing semiconductor testing with live business intelligence – Advantest America
• HPE ProLiant DL360/ DX360 Gen11 #EUDoC TPS-I022
• Hewlett Packard Enterprise and TAURIA partner to deliver enterprise-scale quantum-safe security solutions
• HPE Reference Configuration for Red Hat OpenShift Virtualization on HPE ProLiant DL360 and DL380 Gen11 servers using Red Hat OpenShift Container Platform 4.15
• Hewlett Packard Enterprise and TAURIA partner to deliver enterprise-scale quantum-safe security solutions

[1] Hardware RAID controller support in EDSFF storages available Q2 2024
